Double Stage Powder Metallurgy Planetary Gear Reducer Drive Planetary Gearbox Reducer for Brushless DC Motor
- Overview
- Recommended Products
SPECIFICATIONS |
STAGE |
RATIO |
RATED TORQUE (N.m) |
FLF57 Planetary Gearbox |
L1 |
4 |
25 |
5 |
28 |
||
10 |
10 |
||
L2 |
20 |
25 |
|
25 |
25 |
||
50 |
20 |
||
Rated Input Speed (rpm) |
1000 |
||
Max Input Speed (rpm) |
2000 |
||
Backlash |
L1 |
≤ 30Arcmin |
|
L2 |
≤ 45Arcmin |
||
Fault stop torque(N.m) |
2 times of rated torque |
||
Efficiency |
L1 |
90% |
|
L2 |
80% |
||
Average life span |
20000h |
||
Operating temperature |
-20°~+150° |
||
Nosie |
≤55 db |
||
IP |
54 |
||
Installation method |
Any installation method |
||
L1
L1-R6.25
L2
L2-R6.25
